3. This machine structure is compact, small installation dimensions, packing parts is small, easy to vertical and use.
Model
|
EWW-18
|
EWW-20
|
Machine weight (T)
|
1.8
|
2±0.2
|
Overall dimension (L*W*H)
|
3500*1150*2300
|
3550*1200*2200
|
Bucket capacity (m³)
|
0.03
|
0.12±0.015
|
Max. excavating height (mm)
|
≧3000
|
≧3130
|
Max. excavating depth (mm)
|
≧1500
|
≧1700
|
Min. ground clearance (mm)
|
≧200
|
≧200
|
Max. discharge height (mm)
|
≧2000
|
≧2100
|
Max. vertical dingging depth (mm)
|
≧900
|
≧1200
|
Traveling speed (km/h)
|
0.89
|
0.89
|
Nominal working pressure (Mpa)
|
18/20
|
18/20
|
Rotation angle (°)
|
360
|
360
|
Motor power (kw)
|
11
|
18.5
|
Max. excavation radius (mm)
|
≧3400
|
≧3500
|
Max. digging force (bucket) (kN)
|
≧10
|
≧13
|
Climbing ability (°)
|
≦15
|
≦18
|
Ground pressure (Mpa)
|
≦0.08
|
≦0.08
|
Min. turning radius of truck (m)
|
≦1.6
|
≦1.7
|
